UNIVERSAL HIMALAYAN SALT KIT

• Authentic Himalayan Salt Bricks

• Warm Ambient Glow

• Ability to operate through existing Sauna Power Unit

• Low-voltage LED Lights

• Available in 4” x 48”, 12” x 48”, and 16” x 48 sizes

• Customization (each kit can be modified in length)

• Authentic pink Himalayan salt bricks, 4” x 8” x 2” thick

• Low-voltage, IP67 (waterproof), and sauna-safe components

• White neon LED illumination (no dots – complete diffusion)

• Stainless Steel mounting channels (no glues or adhesives)

• Operates with digital sauna heater controllers or a standard, on/off light switch

4" x 48"

• Salt Brick Color: Pink

• Salt Brick Dimensions: 4"H x 8"W x 2"D

• Salt Feature Dimensions: 4"H x 48"W x 4 1/8"D

• Salt Brick Weight: 5 lbs

• Salt Feature Weight: 34 lbs

• Mounting Channel Dimensions: 15/16”H x 47 3/4”W x 2 7/8”D

• Mounting Channel Weight: 1.6 lbs

• Mounting Channel Material: Stainless Steel

• LED Strip Quantity: 1

• LED Wattage: 12W (White)

• Power Supply: 90W

12" x 48"

• Salt Brick Color: Pink

• Salt Brick Dimensions: 4"H x 8"W x 2"D

• Salt Feature Dimensions: 12 1/4”H x 48”W x 4 1/8”D

• Salt Brick Weight: 5 lbs

• Salt Feature Weight: 97 lbs

• Mounting Channel Dimensions: 15/16"H x 47 3/4"H x 2 7/8"D

• Mounting Channel Weight: 1.6 lbs

• Mounting Channel Material: Stainless Steel

• LED Strip Quantity: 3

• LED Wattage: 36W (White)

• Power Supply: 90W

16" x 48"

• Salt Brick Color: Pink

• Salt Brick Dimensions: 4"H x 8"W x 2"D

• Salt Feature Dimensions: 16 3/8"H x 48"W x 4 1/8"D

• Salt Brick Weight: 5 lbs

• Salt Feature Weight: 124 lbs

• Mounting Channel Dimensions: 15/16"H x 47 3/4"W x 2 7/8"D

• Mounting Channel Weight: 1.6 lbs

• Mounting Channel Material: Stainless Steel

• LED Strip Quantity: 4

• LED Wattage: 48W (White)

• Power Supply: 90W

Himalayan Salt Brick

• Dimensions: 4”H x 8”L x 2”D

• Color: Pink or White

• Channel Notch: All 4 Sides

• Weight: 5 lbs

White LED (4 ft)

• Operating Voltage: 24 VDC

• Rated Wattage: 3W/ft

• Actual Wattage: 12W

• Lumens: 330

• Connection: IP67 Twist Lock 2 Pin

• Connection Length: 10"

• Operating Temperature: -13°F to 230°F

• IP Rating: IP67

• Certification: ETL/SGS

90W Power Supply

• Input Voltage: 120 VAC

• Output Voltage: 24 VDC

• Power Consumption: 90W

• Nominal AC Amperage: 1.3A

• Nominal DC Amperage: 3.75A

• Operating Temperature: -22° to 158°

• IP Rating: IP20

• Certification: UL/CE/FCC

RF Driver (Use for all systems)

• Input Voltage: 24 VDC

• Output Voltage: 12-24 VDC

• Rated Out Current: 5CH, 3A/CH

• Max Output Power: 5CH x 72W

• Light Capacity: 4 Lights/25' (Per Driver)

• Operating Temperature: -22°F to 131°F

• IP Rating: IP20

• Certification: UL/CE/FCC

• Himalayan Salt Brick, Pink

• Salt Block Mounting Channel

• IP67 LED Strip Light

• Power Supply

• Light Cables

• Flat Rate Parcel Shipping - 4”system: (Included) $98.00 flat rate freight shipping to the contiguous United States. $149.00 for Canada. Note: On rare occasions, remote or complex delivery areas may not qualify for these rates.

• Flat Rate LTL Truck Shipping - 12” & 16” systems: (Included) $249 flat rate shipping to the contiguous United States. $349.00 for Canada. Note: On rare occasions, remote or complex delivery areas may not qualify for these rates.

• About This Delivery: The weight and packaging of these 12” & 16” dynamic Himalayan salt systems require delivery by special appointment. They arrive on a wooden pallet encased in Heavy-duty cardboard for solid protection. The driver is responsible for “curbside delivery only” and will lower the items to ground level. Prior to shipping this product, we often contact customers to share shipment details and discuss any extenuating delivery circumstances that may complicate or cause additional delivery expenses. The 4” system ships FedEx parcel.

**Note to Canadian customers: We will need your customs broker information for all palletized orders. For more info on import duties and fees, visit our FAQs.

Installation Manual

Rough In Specs: 4”x48”, 12”x48”, 16”x48”
