SAUNUM AIR L 13 13.0KW WIFI SAUNA HEATER PACKAGE
All sauna bathers have experienced the same issue – extreme variance in temperature and oxygen from the ceiling to the floor. The temperature at the ceiling can often exceed 200°F, while at the floor it will be under 100°F, causing your feet to feel uncomfortably cool and your head to be too hot. The temperature and oxygen level should be more consistent throughout.
This revolutionary sauna heater includes an ingenious climate equalizing system that more evenly balances the temperature and oxygen levels throughout your sauna for softer, more breathable air.
Saunum is all about the air!
• The AIR we heat
• The AIR we feel
• The AIR we breathe
Enrich the air with Himalayan salt ions
The ions released from the patented Himalayan salt feature are propelled into the sauna to maximize their health benefits. Salt aerosol has long been used for its benefits as a decongestant, inflammation reduction, and possesses anti-microbial properties.
Add another dimension to your sauna with aromatherapy
Breathe deep, relax, let the room fill with heat and steam, and clear away your tension with the invigorating and awakening scents of Saunum’s available aromatherapy option.
-
Air L 13 Sauna Heater
Revolutionary Air Mixing Technology – No more cold feet! No other sauna heater has Saunum's patented air blending system, which mixes cooler, oxygen-rich air from the floor with hot, oxygen-poor air off the ceiling and distributes it throughout the room for a more even temperature and better breathability. Saunum ensures that heat and oxygen are more consistent from head to toe.
Scandinavian Design – With its elegant black steel finish, Saunum combines contemporary Scandinavian design and premium-quality materials.
Massive Stone Capacity – Stones are the heart of a Nordic sauna. Greater stone capacity results in softer, more even heat, and can produce more luxurious steam. The Air L boasts a massive 265 pound stone capacity.
Himalayan Salt Reservoir – Himalayan Salt Spheres are positioned within the air stream so that salt ions are propelled throughout the sauna to deliver health benefits more effectively.
Wi-Fi Control – The available AirIQ Wi-Fi Control allows you to activate a tailored sauna profile and have your custom sauna ready at the time that you specify on your mobile device.
Dry your Sauna – Go ahead, toss water onto the rocks! Saunum is engineered for water-tossing, and when you're done enjoying the steam, the patented fan system will conveniently help dry your sauna.
UL Certification – Safety and reliability are priorities at Saunum, and each product is engineered to exceed strict UL standards.
Available Aromatherapy – Add another sensory layer with Saunum's optional aromatherapy system, which infuses aroma into the steam to further transform your experience.
For sauna rooms from 317 to 565 cu. ft.
AirIQ Wi-Fi Control
Temperature selection ranges from 104°F - 194°F (40°C - 90°C)
Allows you to set the operating time of the heater: Up to 1 hour in a private sauna, up to 6 hours in a public sauna
Allows you to select up to 3 preset sauna settings: Selectable temperature, time, climate device speed
Classic Nordic Steam Sauna
For temperatures from 140°F - 194°F (60°C - 90°C). Valve of the Climate Device open to 25% with speed level 1.
Humid Steam-Rich Sauna
For temperatures from 113°F - 140°F (45°C - 60°C). Valve of the Climate Device open to 100% with speed level 2 or 3.
Mild, Relaxing Sauna
For temperatures from 104°F - 131°F (40°C - 55°C). Valve of the Climate Device open to 25% with speed level 1.
AirIQ Wi-Fi allows for sauna session scheduling for a specific day, time, and sauna type for the week
Built-in Wi-Fi interface for Saunum mobile app available on AppStore and Google Play
Modbus integration for smart home connection
Notifications will be conveniently displayed directly onto your mobile device via the Saunum mobile app
Sauna is Ready
Heating Status
Door is Open
Overheating Protection Applied
Multi-language menu includes English, German, Estonian, Finnish, Russian, Swedish, and Slovenian
Outside sauna room installation
Screen lock
Child safety lock
Temperature sensor
Door sensor
Sauna Stones
High-quality olivine diabase raw stone
Rounded, pre-washed, and ready to use
Durable with high-heat capacity
Stones range from 2" to 4" (5-10 cm)
-
AIR L 13 PKG
Heat Equalizing System
Model: AIR L 13
Certification/Global Safety Rating: UL (Underwriters Laboratories)
Heat/Steam Equalizer Module: 3-Speeds, Whisper-Quiet Operation
Ceiling Hot Air Intake: 17.72" x 4" (450.09 x 101.6mm)
Cool Air Intake Type: Adjustable Valve, Side-Mounted, 12" (304.8mm) Off Floor
Cool Air Intake Size: 2" x 2.75" (50.8 x 69.85mm)
Blended Air Output: 4.31" x 14.13" (109.47 x 358.9mm)
Himalayan Salt and Aroma Tray Type: Removable, Slotted
Himalayan Salt and Aroma Tray Size: 16.5" x 4.5" (419.1 x 111.76mm)
Sauna Heater System
Model: AIR L 13
Certification/Global Safety Rating: UL (Underwriters Laboratories)
Room Size: 317-565 cu.ft.
Wattage Rating: 13000
Operating Voltage: 240V
Phase: Single
Amperage: 54A
Circuit Breaker: 70A
Wire Size to Power Unit: (2) #6 + N + G
Minimum Ceiling Height: 79" (2007mm)
Stone Capacity: 265 lbs (120 kg)
Stone Size: 2" - 4" (5-10 cm)
Heater Width: 19" (483mm)
Heater Depth: 18.1" (460mm)
Heater Height (Including Telescopic Air Intake): 72.25-95" (1850-2400mm)
Heater Weight: 147 lbs (67 kg)
Shipping Weight with Stones: 412 lbs (187 kg)
Display Panel
Model: AIRIQ WI-FI
Certification/Global Safety Rating: UL (Underwriters Laboratories)
Type: Digital, Soft-Touch
Response: Tactile with Haptic Feedback Technology
Language Selection: 16-Languages
Wi-Fi Capability: Wi-Fi, App-Based Updates, and Operation
Notifications: Sauna is Ready, Heater Status, Open Door, and Overheating Protection
Safety Features: Admin, Screen Lock, Door Sensor, and Overheating Protection
Color: Nordic Black
Heat Equalizing Control: 3-Speed Adjustability
Width: 3.3" (83.82mm)
Depth: .8" (20.32mm)
Height: 4.1" (104.14mm)
IP Rating: IP20
Minimum Temperature Setting: 104°F (40°C)
Maximum Temperature Setting: 194°F (90°C)
Duration Timer: 1 - 6 Hours
Display Panel Cable: 4-Conductor Cable (150°C), 20AWG, 15' (475.2 cm)
Door Sensor and Cable Assembly (Included with Heater): 2-Conductor Cable (150°), 20AWG, 9.83' (299.62 cm)
Door Sensor Probe: 1"L x .24"Diameter (25 x 6mm)
Operating Temperature Range: -4 - 145°F (-20 - 62°C)
Programmability: Weekly Scheduling with 3 Programmable Sessions
Temperature Settings: Fahrenheit or Celsius
Region Settings: North American and European Versions
Room Temperature Sensor (Included with Heater): Pre-Mounted with Integrated Cable (150°C), 9.5' (289.56 cm)
-
Air L 13 Sauna Heater
13kW Sauna Heater
Himalayan Salt Spheres (7)
Himalayan Salt Tray
Hot Air Intake Cap
Hot Air Intake
Stone Basket
Air Outake Grille
Cool Air Intake Valve
Protective Grill
Temperature Sensor
Installation and Operation Manual
2-Year Limited Warranty (Consumer Use) and 1-Year Limited Warranty (Commercial Use)
AirIQ Wi-Fi Control
Soft-Touch Display Panel (Wi-Fi App-Based Updates and Operation)
Wall Mounting Plate and Fasteners
Power Unit
Door Sensor Magnet
Installation and Operation Manual
2-Year Limited Warranty (Consumer Use) and 1-Year Limited Warranty (Commercial Use)
Sauna Stones
265 lbs of 2" to 4" (5-10 cm) Round Sauna Stones
-
Current ETA: 1-2 weeks. Shipping lead time is subject to change.
FREE shipping within the contiguous United States.
The weight or packaging of this product requires delivery by special appointment. It arrives on a wooden pallet and is encased in three-ply cardboard for solid protection.
The driver is responsible for curbside delivery only and will provide limited assistance at the site.
Prior to shipping this product, we’ll contact the customer to share shipment details and discuss any extenuating delivery circumstances that may complicate or cause additional delivery expenses.
Sauna accessories can be shipped with this sauna heater to save on shipping costs.
**If you’re in Canada, please reach out for a shipping quote. We will need your customs broker information for all palletized orders. For more info on import duties and fees, visit our FAQs.
-
